micnode mini6
Compact six button microphone station with OLED display
AVAILABLE TO ORDER
The micnode mini6 is a compact microphone station designed for comfortable use, featuring a built-in display for easy operation. It is compatible with QSC ™ Q-SYS and can be used as part of Q-SYS paging system. Supporting modern audio standards such as AES67, RTP, and VoIP, the micnode mini6 ensures reliable network communication while enhancing security with an additional encryption layer to protect transmissions from unauthorized access. A built-in secure enclave element further ensures safe connectivity to leading cloud service providers. Additionally, it’s ready to integrate with Simpleway CX cloud solutions straight out of the box.
Easy to use and cost-efficient microphone station
OLED Display for zone selection and status information
Compatible with Q-SYS
Process audio using build-in processing engine
Keep your audio streams private by adding encryption to industry standard audio protocols such as AES67
Trust your audio devices following latest IT and physical security standards
Securely connect your infrastructure to cloud systems such as Simpleway CX cloud
Key highlights
6 zones with indicator LEDs
The micnode mini6 is an easy to deploy
and easy to use six–zone microphone station.
OLED User Interface
OLED Display for zone selection and status information
Connect with cloud
A secure–enclave element built in enables secure connectivity to all major industry cloud providers. The device can be used with Simpleway CX cloud out of box.
Third-party compatibility
Can be used as part of Q-SYS paging system.
| Description | Compact six button microphone station with OLED user interface |
| Audio | Dynamic microphone Configurable microphone preamplifier with -8 dB to 34 dB gain AD Converter: 24 Bit @ 48 kHz 117 dB - A Dynamic Range - 0.00x % THD+N |
| Connectivity | 1 x RJ45 input for connecting a dynamic microphone 1 x LAN RJ45 1000 Mbps with PoE |
| DSP | 60+ Component library API library |
| User Interface | OLED 6 x Zone select button with indicator LED's Web-based configuration interface Cloud-connected |
| Security | Secure boot Encrypted firmware Secure enclave chip Optional AES256–GCM encryption for AES67 |
| Compatibility | Q–SYS compatible |
| Environmental | Operating temperature range 32 °F – 122 °F (0 °C – +50 °C) Storage temperature range 14 °F to 140 °F (–10 °C – +60 °C) |
| Power | IEEE 802.3af power over Ethernet (PoE), Power consumption: typical 6W, max. 12W |
| Dimensions | 157 mm (W) x 40 mm (D) x 103 mm (H) US 3–gang box compatible 400 g without microphone Microphone cable length: min. 80 cm (31.5 “), can be stretched to a length of up to 110 cm (43.3”) |
| Accessories | Mounting kit, Handheld microphone, Desk stand (optional) |
Specifications
Visit the Download Center for product resources
Bridging the Gap Between Sound and Vision
While nnounce devices are fully integratable with other PA ecosystems, such as Q-SYS, their true power emerges when perfectly paired with Simpleway’s digital signage and public address cloud software, creating a uniquely cohesive and effective communication experience.
Retail, hospitality, educational, healthcare sectors, warehouses, company campuses, and more can adopt the nnounce platform with Enterprise CX system, meeting diverse communication needs and empowering synchronized messaging across environments.
nnounce products paired with Airport CX elevate the passenger experience for airports of all sizes. Operators can instantly trigger announcements for specific flights or trips, with displays automatically updating to show accurate, real-time information, keeping travelers informed and enhancing their journey.
For ground public transport, including trains, ferries, and buses, the Transit CX platform unified with nnounce devices allows for robust and timely management of location-specific announcements and visual information updates throughout entire transportation networks.
Explore our whole nnounce family
